AT-8202 ATM Uplink User’s Guide
2-9
To associate a CIP entity with an SVC:
1. Enter option 6b for an SVC connection type.
6=b
2. Enter
7=
This entry must be in 20-octet hex format, and this parameter
is mandatory for a CIP entity over SVC.
Note
Any connections for the CIP over SVC are possible only after the
FORMULA 8200 switch has completed the ATM address registration
with the ATM switch.
To associate a CIP entity with a PVC:
1. Enter option 6a for PVC connection type.
6=a
2. Enter option 7a to add a value to the VCI list.
7=a
The system prompts you for a VCI value:
3. Enter a unique VCI value, i.e., it does not correspond to an existing
connection.
Arp Server ATM Address The ATM address of the ARP server; not used for PVC connections
but mandatory if the connection type is SVC
Mtu Size Maximum transfer unit size for data transfer for this entity
Default is 9180 as defined in RFC 1577.
IP RIP Mode Routing information protocol mode for this CIP entity
Options: Active, Silent, Deaf, Inactive
Table 2-2 ATM/CONFIG/CREATE/CIP Parameters (Continued)
Parameter Description
Enter VCI value to be added to the VCI list:
