AT-8202 ATM Uplink User’s Guide
1-5
To configure CIP services:
1. Use the VLAN/SHOW/VLAN command to verify that a valid IP
address exists.
The VLAN/SHOW/VLAN command displays the following
information:
2. Create the CIP service using the ATM/CONFIG/CREATE/CIP
command.
The valid CIP index values are from 0-15.
A sample screen is shown in Figure 1-2. Table 1-2 provides a
description of each parameter.
Figure 1-2 Configuring CIP
/VLAN/SHOW/VLAN
Virtual LAN Information:
VLAN VLAN IP Network Admin Operation Port
ID Description Address Status Status Membership
==== =============== ========== ====== ========= ==========
1 Default VLAN(#1 1.1.1.1 ENABLE ACTIVE 1-16
/ATM/CONFIG/CREATE >
CIP 7
CIP Configuration
1. CIP Index: 7
2. IP Address: 137.168.132.7
3. IP Subnet Mask: 255.255.255.0
4. Description (Optional): CIP Test 7
5. Admin Status (ENABLE(a), DISABLE(b)): ENABLED
6. Connection Type (PVC(a), SVC(b)): SVC
7. VCI Value (Reqd if PVC):
8. Arp Server ATM Address (Reqd if SVC):
9. Mtu Size: 9180
10. RIP mode (Active (a), Deaf (b), Silent (c), Inactive (d)): 0
Enter Selection, 0 to save the Modification or ‘q’ to Quit: 0
