AT-8202 ATM Uplink User’s Guide
2-25
ATM/SHOW/CONNECTION Example
This command displays a summary of all open ATM virtual channel
connections. A sample display of
ATM/SHOW/CONNECTION is
shown below, and parameters are described in Table 2-11.
Table 2-10 ATM/SHOW/CIP Parameters
Parameter Description
CIP Index Index of this CIP entity
CIP Name A default name for this entity
Description Optional text description of up to 31 characters
IP Address Takes the same IP network number and subnet number of the LIS (logical
IP subnetwork)
IP Subnet Mask Subnet mask for this LIS entity
Admin Status Administrative status
Options: Enable or disable
Connection Type Connection type
Options: PVC or SVC
Server ATM Address If the connection type is SVC, the ATM address of the ARP server
Mtu Size Maximum transfer unit size for data transfer for this entity
Default: 9180, as defined in RFC 1577
RIP Mode Routing internet protocol mode for this CIP entity
Default: Silent
Protocol State Operational state of the CIP
Active indicates that the connection to ARP server is up (only displayed if
administrative status is enabled and connection type is PVC)
Options: Active, inactive, connect request sent, unknown
ARP Server VCC VCI value of the connection to ARP server (only displayed if administrative
status is enabled and connection type is PVC)
Data VCC Connections Shows the list of VCI values of the data connections to destinations, if any
(only displayed if administrative status is enabled, connection type is PVC,
and there are data connections to other CIP entities)
