AT-8202 ATM Uplink User’s Guide
2-27
.
/ATM/SHOW > CONNECTION 70
Virtual Connection Configuration for VCI 70
Circuit Type: SVC
Service Type: Cip
Status: Active
Connection Up For: 249 Seconds
Requested Tx. Qos Class(Choices: a - e): Unspecified
Requested Tx. BestEffort((a) = TRUE, (b) = FALSE): True
Requested Tx. Peak Cell Rate (cells/sec) 353208
Requested Rx. Qos Class(Choices: a - e): Unspecified
Requested Rx. BestEffort((a) = TRUE, (b) = FALSE): True
Requested Rx. Peak Cell Rate (cells/sec) 353208
Table 2-12 ATM/SHOW/CONNECTION Parameters
Parameter Description
Circuit Type PVC or SVC
Service Type The kind of service provided over this connection (examples: ILMI,
signaling, CIP, LEC)
Status Operational status of this connection
Connection Up For How long this connection has been up
Requested Tx. Qos Class QOS class for transmit for this connection
Requested Tx. BestEffort Whether the connection is setup for best effort for transmit
False=Connection is disabled if peak cell rate cannot be supported with
available bandwidth.
True=Connection uses available bandwidth.
Requested Tx. Peak Cell Rate The peak cell rate in cells per second for this connection in the transmit
direction
Requested Rx. Qos Class QOS class for receive for this connection
Requested Rx. BestEffort Whether the connection is set up for best effort for receive
False=Connection is disabled if peak cell rate cannot be supported with
available bandwidth.
True=Connection uses available bandwidth.
Requested Rx. Peak Cell Rate The peak cell rate in cells per second for this connection in the receive
direction
