ATM/CONFIG/CREATE Commands
2-14
ATM/CONFIG/CREATE/TRUNK Example
This command allows you to configure the trunking feature. A
sample display of
ATM/CONFIG/CREATE/TRUNK
Number> is shown below, and parameters are described in Table 2-5.
.
/ATM/CONFIG/CREATE > trunk 7
TRUNK Configuration
1. TRUNK Index: 7
2. Description (Optional): TRUNK Instance 7
3. Admin Status (ENABLE(a), DISABLE(b)): ENABLED
4. Connection Type (PVC(a), SVC(b)): PVC
5. VCI Value (Reqd if PVC):
6. Destination ATM Address (Reqd if SVC):
Enter Selection, 0 to save the Modification or 'q' to Quit: 0
Table 2-5 ATM/CONFIG/CREATE/TRUNK Parameters
Parameter Description
TRUNK Index The unique value assigned to this trunking entry
Description This optional text description can be up to 32 characters long
Admin Status Determines whether the administrator can update the parameters
Range: Enable or Disable
Default = Enable
Connection Type Specifies the CIP service
If set to PVC, you must have at least one entry in the VCI list.
If set to SVC, you must enter an address in the Destination ATM
Address field (item 6 on the screen).
Range: PVC or SVC
Default: PVC
VCI Value (Reqd if PVC) The virtual channel identifier; for PVC connections only
Disabled if SVC is selected in the Connection Type field (item 4 on the
screen)
Accepts one VCI entry only
Range: 32-1023
Default: 32
Destination ATM Address (Reqd if
SVC) The ATM address of the other end point of the connection
Required when SVC is selected as the Connection Type (item 4 on the
screen)
