ATM/CONFIG/MODIFY Commands
2-20
.
/ATM/CONFIG/MODIFY > PORT
Atm Port Configuration
1. ATM PVC/SVC Mode (PVC mode (a), SVC mode (b)): SVC mode
2. Signaling Version (3.0(a), 3.1(b)): Uni 3.0
3. ILMI Enable (Enable(a), Disable(b)): Enable
4. ILMI Poll Enable (Enable(a), Disable(b)): Disable
5. Scrambling Enable (Enable(a), Disable(b)): Enable
6. Timing Mode (Loop(a), Local(b)): Local
7. Port ATM Address
Enter Selection, 0 to save the Modification or 'q' to Quit: 0
Table 2-6 ATM/CONFIG/MODIFY/PORT Parameters
Parameter Description
ATM PVC/SVC mode Whether this service provides a permanent virtual circuit or switched
virtual circuit
Signaling Version
(If SVC) Currently the FORMULA 8200 switch supports UNI 3.0 or UNI 3.1. Set
this value depending upon the user-to-network (UNI) support on the
ATM switch to which you have connected the FORMULA 8200. Reset
the switch when the setting for signaling version changes.
Default: UNI 3.0
ILMI Enable
(If SVC) Address registration between an ATM end system and an ATM switch
across the UNI
Options: Enable or disable
Default: Enable
ILMI Poll Enable
(If SVC) Polling feature for checking address registrations between an ATM end
system and an ATM switch across the UNI
Options: Enable or disable
Default: Disable
Scrambling Enable Bit randomization of cells to increase security
Options: Enable or disable
Default: Enable
Timing Mode Timing mode for either the internal (local) or external (loop) clock
Options: Local or loop
Default: Local
Port ATM Address The ATM address for this port
