ATM/CONFIG/CREATE Commands
2-8
/ATM/CONFIG/CREATE >CIP 7
CIP Configuration
1. CIP Index: 7
2. IP Address: 137.168.132.7
3. IP Subnet Mask: 255.255.255.0
4. Description (Optional): CIP Test 7
5. Admin Status (ENABLE(a), DISABLE(b)): ENABLED
6. Connection Type (PVC(a), SVC(b)): SVC
7. VCI List (Add to List (a)):
8. Arp Server ATM Address (Reqd if SVC): 0x47000580ffe1000000f21514950
0204815149500
9. Mtu Size: 9180
10. IP RIP mode (Active (a), Deaf (b), Silent (c), Inactive (d)): Silent
Enter Selection, 0 to save the Modification or 'q' to Quit: 0
Table 2-2 ATM/CONFIG/CREATE/CIP Parameters
Parameter Description
CIP Index The unique value assigned to this CIP entity
Range: 0-15
IP Address A mandatory entry, this takes the same IP network number and
subnet number of the logical IP subnet (LIS).
IP Subnet Mask A mandatory entry, this is the subnet mask for this LIS entity.
Description Optional text description, up to 31 characters long
Admin Status Determines whether the administrator can update the parameters
Options: Enable or Disable
Default: Enable
Connection Type Specifies the CIP service
If set to PVC, you must have at least one entry in the VCI list. If set to
SVC, you must enter an ATM address in the Arp Server ATM Address
field (item 8 on the screen).
Options: PVC or SVC
Default: PVC
VCI List The value for the virtual channel identifier for PVC connections only
Disabled if SVC is entered in the Connection Type field (item 6 on
the screen)
Accepts one VCI entry only
Range: 32-1023
Default: 32
Additional options: A to add or B to delete the value from the VCI list
