AT-8202 ATM Uplink User’s Guide
2-13
.
/ATM/CONFIG/CREATE > ptop 7
PTOP Configuration
1. PTOP Index: 7
2. Description (Optional): PTOP Instance 7
3. Admin Status (ENABLE(a), DISABLE(b)): ENABLED
4. Encapsulation Type (RFC1483(a), Proprietary(b)): RFC1483
5. Connection Type (PVC(a), SVC(b)): PVC
6. VCI Value (Reqd if PVC):
7. Destination ATM Address (Reqd if SVC):
Enter Selection, 0 to save the Modification or 'q' to Quit: 0
Table 2-4 ATM/CONFIG/CREATE/PTOP Parameters
Parameter Description
PTOP Index The unique value assigned to the PTOP entry
Description (Optional) Optional text description of up to 32 characters
Admin Status Determines whether the administrator can update the parameters
Range: Enable or Disable
Default = Enable
Encapsulation Type Indicates the encapsulation format for this PTOP entry
Range: RFC1483 or Proprietary
Only RFC1483 is accepted at this time.
Default = RFC1483
Connection Type Specifies the CIP service
If set to PVC, you must have at least one entry in the VCI list.
If set to SVC, you must enter an address in the Destination ATM Address
field (item 7 on the screen).
Range: PVC or SVC
Default = PVC
VCI Value (Reqd if PVC) The virtual channel identifier; for PVC connections only
Disabled if SVC is selected in the Connection Type field (item 5 on the
screen)
Accepts one VCI entry only
Range: 32-1023
Default: 32
Destination ATM Address
(Reqd if SVC) The ATM address of the ARP server for the logical IP subnet to which this
CIP is connected
Required when SVC is selected as the Connection Type (item 5 on the
screen).
