AT-8202 ATM Uplink User’s Guide
1-15
8. Enter 1 as the ATM/PTOP selection :
9. Enter a port service description (optional) or press [ENTER] to see
the following messages:
10. Verify that PTOP services have been created by using the ATM/
SHOW/PTOP command.
11. Verify that PTOP services are bound by using the PORTSERV/
SHOW/PORTSERV 34 command.
You have successfully configured PTOP on this switch. See Chapter 2,
ATM Commands,
for other PTOP commands.
Enter a ATM/PTOP selection (c to cancel)> 1
Port Service Description (PS of ATM/PTOP 1) PTOP test:
Port service 2 is created for physical port 34
Port service 2 is bound with ATMPTOP 1
Updating system/VLAN configuration....
/ATM/SHOW > PTOP 1
PT-PT 1 Display
PTOP Index: 1
Description: PTOP Instance 1
Admin Status: ENABLED
Encapsulation Type: RFC1483
Connection Type: PVC
VCI Value: 501
Dest ATM Address:
/PORTSERV/SHOW > PORTSERV 34
Phyport Phyport Phyport PortServ PortServ Admin Operation VLAN
ID Type Number Type/ID Description Status Status Number
=== ======== ======= ========== =========== ====== ======== ======
34 ATMOC3 1 ATMPTOP/1 PTOP test ENABLE ACTIVE 1
