AT-8202 ATM Uplink User’s Guide
2-11
/ATM/CONFIG/CREATE > LEC 1
LEC Configuration
1. LEC Number: 1
2. LEC Description (Optional):
3. ELAN Name(applicable only in AUTO mode):
4. Use LEC Config Server(Yes(a), No(b)): Yes
5. LEC Config Server ATM Address(Option 5a): 0x47007900000000
00000000000000a03e00000100
6. Control Time-out (in seconds): 10
7. Max. Unknown Frame Count: 1
8. Max. Unknown Frame Time(in seconds): 1
9. VCC Time-out(in seconds): 1200
10. Max. Retry Count: 1
11. Ageing Time (in seconds): 300
12. Expected LE-ARP Resp Time (in seconds): 30
13. Flush Time-out (in seconds): 4
Enter Selection, 0 to save the Modification or 'q' to Quit: 0
Table 2-3 ATM/CONFIG/CREATE/LEC Parameters
Parameter Description
LEC Number The unique index for this LEC
Range: 0-31
LEC Description Optional text description of up to 31 characters
ELAN Name The name of the ELAN of which this LEC is a member (AUTO mode
only)
Use LEC Config Server Configuration mode
Options: Yes or No
Default: No
LEC Config Server ATM Address If the Configuration mode is Yes, the ATM address of the LECS
If the Configuration mode is No, the ATM address of the LAN emulation
server (LES)
Control Time-out Maximum amount of time for a LEC’s join request to remain
unanswered, after which the LANE entity holding the request frame
discards it
Range: 10 – 300 seconds
