AT-8202 ATM Uplink User’s Guide

1-13

Note

You must enter a VCI value when configuring a PVC connection type.
Additionally, make sure the PVC number is identical on all
FORMULA 8200 switches.

3. Enter

for VCI value configuration at the prompt.

4. Enter

501

as the VCI value when prompted.

/ATM/CONFIG/CREATE >

PTOP 1

PTOP Configuration

1. PTOP Index:

2. PTOP Description (Optional):

PTOP Instance 1

3. Admin Status(ENABLE(a),DISABLE(b):

ENABLED

4. Encapsulation Type:(RFC1483(a),Proprietary

RFC1483

5. Connection Type (PVC(a), (SVC(b):

PVC

6. VCI value (Reqd if PVC):

7. Destination ATM Address (reqd if SVC):

Enter Selection, 0 to save the Modification or ‘q’ to Quit: 0

Enter VCI value: 501
