Configuring the ATM Port
1-2
Configuring the ATM Port
This section describes the first of a two-part process to configure the
ATM network.
To configure an ATM port, use the ATM/CONFIG/MODIFY/PORT
command to display screen similar to Figure 1-1.
Figure 1-1 ATM Port Configuration Screen
Refer to Table 1-1 for a description of the port configuration
parameters.
/ATM/CONFIG/MODIFY > PORT
ATM Port Configuration
1. ATM PVC/SVC Mode (PVC Mode (a), SVC Mode (b)): SVC Mode
2. Signaling Version (3.0(a), 3.1(b)): Uni 3.0
3. ILMI Enable (Enable(a), Disable(b)): Enable
4. ILMI Poll Enable (Enable(a), Disable(b)): Disable
5. Scrambling Enable (Enable(a), Disable(b)): Enable
6. Timing Mode (Loop(a), Local(b)): Local
Enter Selection, 0 to save the Modification or q to quit:
Table 1-1 ATM Port Configuration Parameters
Parameter Description
PVC/SVC Mode Whether this port is configured for permanent virtual circuit or switched virtual
circuit mode
Signaling Version The FORMULA 8200 supports UNI 3.0 or UNI 3.1. Set this value depending
upon the UNI support on the ATM switch to which you have connected the
FORMULA 8200. Reboot the switch when the setting signaling version changes.
Default: UNI 3.0.
ILMI Enable ILMI provides network management (NMS) between an end-user and a public
or private network. ILMI functions for configuration, status, and control
information about the physical and ATM layer parameters are available for the
ATM interface.
Options: Enable or disable
Default: Enable
