Horner APG XL7 OCS User Manual
Page 94
XL7 User Manual
The OCS follows the following sequence in execution of AutoLoad:
Power up OCS
Application Program absent
or
Application Program corrupted
AutoLoad
Enabled?
AUTOLOAD.PGM present in
the RM of the device ?
AutoLoad initiated.
OCS put in IDLE mode
AutoLoad run sequence
failed (with reasons for
failure)
NO
NO
YES
YES
AutoRun
Enabled?
OCS put in RUN Mode
OCS put in IDLE Mode
NO
YES
Figure 16.8 – Flow Chart for AutoLoad
Page 94 of 110
