XL7 User Manual
Clone
Selecting “Clone Unit” menu will open the following menu screen:
Note: Free/Total – displays number of free and total bytes in Removable Media.
Selecting Make Clone brings up the confirmation screen. Upon confirmation, the OCS will create two
new files in the root directory of the Removable Media Drive as shown below:
AUTOLOAD.PGM Application file
CLONE.DAT File having all unit settings and register values from Battery Backed RAM
Load Clone
Selecting “Clone Unit” menu will open the following menu screen. Select “Load Clone”.
NOTE: For security enabled files, Load clone asks for password validation before loading the application.
