14.3 Register Map for XL7 OCS I/O
Table 14.4 – Register Map for XL7 OCS I/O
Fixed
Address Digital/Analog I/O Function
XL7 Model
2 3 4 5
%I1
Digital Inputs 1-12 1-12 1-24 1-12
Reserved 13-32 13-31 25-31 13-31
ESCP Alarm n/a 32 32 32
%Q1
Digital Outputs 1-6 1-12 1-16 1-12
Reserved 7-24 13-24 17-24 13-24
%AI1
Analog Inputs 1-4 1-2 1-2 1-2
Reserved 5-12 3-12 3-12 3-12
%AQ1
Reserved n/a 1-8 1-8 1-8
Analog Outputs n/a n/a n/a 9-10
Reserved areas maintain backward compatibility with other XL Series OCS models
14.4 Resource Limits
Table 14.5– Resource Limits
Resource Value Resource Value
%S 16 Ethernet
CsCAN, Ping, EGD, SRTP, Modbus TCP
Master (Downloadable protocol) & Slave,
Ethernet IP, FTP, or HTTP @ 10 MBd or 100
MBd
%SR 448 CsCAN 125 kBd, 250 kBd, 500 kBd, or 1 MBd
%T 16000 Serial Ports 1 RS232, 1 RS485 Ports
%M 16000
IDs Per CsCAN
Network
64 w/o repeat (253 w/ 3 repeaters)
%R 49999 Keypad 5 keys (4 fn keys and a System Key)
%K 5 Display 800 x 480 7” TFT, 65K colors
%D 1023 Screen Memory 64 MB
%I 2048 User Screens 1023
%Q 2048
Data Fields Per
User Screen
1023
%AI 512 Ladder Code 1024 kB
%AQ 512
