Horner APG XL7 OCS User Manual
Page 9
XL7 User Manual
Visual map of major tasks and the key chapters to assist you
FIRST STEP of ANY TASK: DATASHEET
Each XL7 OCS unit is sent with a datasheet in the box. The datasheet (MAN0971-02-EN) is the first
document to refer to for model-specific information related to XL7 OCS models such as pin-outs,
jumper settings, and other key installation information. To obtain updates to datasheets, manuals
and user documentation, visit a Horner website (US:
and Europe:
QUICK START
INSTALLATION
PROGRAMMING
TROUBLESHOOTING
Safety / Compliance
Safety / Compliance
Safety / Compliance
Safety / Compliance
Introduction
Introduction
Introduction
Introduction
Mechanical Installation
Serial Communications
Maintenance
Electrical Installation
CAN Communications
Troubleshooting
Ethernet
Communication Options
Removable Media
High Speed I/O
System Settings
User Interface
Registers
Cscape Configuration
Fail- Safe System
Clone Unit
