June 2004 DelphMap™ User's Manual
Layer Manager
The Layer Management dialog box is evocable from three locations: an
icon
on the toolbar, through the Tools menu, and through the menu
options when right clicking in the project window.
When Manage Layers is activated,
the adjacent dialog box opens.
There are individual tab windows for
each layer type (i.e. image and
vector). Only those layers that are
present in the project will appear in a
tab. For example, if there aren’t
vector layers entered in the project,
then only the tab for Image layers will
be present. Likewise, the manage
layer dialog cannot be activated until
there are layers in the Project
Window.
The layer manager can be used to
apply and preview changes to the
project window. All layers can be
toggled for displayed by clicking the
sun icon,
, or hidden by clicking
the eclipse icon,
. In the layer
manager window, once the user has
selected (highlighted) a single layer
there are three options:
Click the green check mark icon
to toggle for displayed/ hidden or the
user can click next to the layer itself.
Click the red “X” icon to remove the file from the Project, or hit the
Delete key.
Chapter 4: Managing Layers 78
