-87-
MODEL
NO.
DESCRIPTION
NEMA
4X/IP65
BEZEL
4 to 20 mA
ANALOG
OUTPUT
0 to 10 VDC
ANALOG
OUTPUT
ALARM
OUTPUTS
COOLING
OUTPUT
RS485
COM
PART NUMBER
TSC
Temperature Setpoint Controller
NO
YES
NO
2
NO
NO
TSC01001
YES
YES
NO
2
NO
NO
TSC11001
YES
YES
NO
1
YES
NO
TSC11002
YES
YES
NO
2
NO
YES
TSC11004
YES
YES
NO
1
YES
YES
TSC11005
YES
NO
YES
2
NO
YES
TSC12004
YES
NO
YES
1
YES
YES
TSC12005
Relay Module
OMD00000
Triac Module
OMD00001
Logic/SSR Drive Module
OMD00003
PMK5
Panel Mount Adapter Kit (1/4 DIN to 1/8 DIN)
PMK50000
RLY5
SSR Power Unit
RLY50000
RLY6
Single Phase 25 A DIN Rail Mount Solid State Relay
RLY60000
RLY6A
Single Phase 40 A DIN Rail Mount Solid State Relay
RLY6A000
RLY7
Three Phase DIN Rail Mount Solid State Relay
RLY70000
These models have dual alarm outputs, or single alarm with cooling outputs, with shared common terminals (Form AA Type). As a result, these outputs should be
fitted with the same type of output module. The main output (OP1) may be fitted with any type of output module.
Note: Output Modules are NOT supplied with the controller. When specifying the controller, be sure to purchase the appropriate output module for the Main Control Output
and if necessary, the alarm output(s) and cooling output. The controller can be fitted with any combination of output modules that do not have the RS-485 option.
The Logic/SSR Drive Module is a switched DC source, intended to drive the DC input of an SSR power unit. It should never be connected to a line voltage.
All modules are shipped separately and must be installed by the user.
APPENDIX “G” - ORDERING INFORMATION
