Red Lion TSC - Manual (Page 57)

Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
CSEt Control Point
set-up
NO
CP-1
CP-2
CP-3
CP-4
(NO)
NO - Return to
CONF
Control Point 1
Control Point 2
Control Point 3
Control Point 4
The parameters for the four Control Points are the same. (n = control point 1, 2, 3, or 4.)
SP-n Setpoint value for
Control Point n
SPLO to SPHI
1 or .1 degree
(0)
Limited to setpoint
limit values.
PId PID gain set for
Control Point n
NO - disable PID,
return to CSEt
yES - continue with
entry of PID
(NO)
PID values to be
loaded with
setpoint entry,
when implemented.
Pb-n Proportional band
for Control Point n
0.0 to 999.9%
(4.0)
0.0% = ON/OFF
control
It-n Integral time for
Control Point n
0 to 9999 seconds
(120)
0 is off. Does not
appear in Pb-n =
0.0%
dt-n Derivative time for
Control Point n
0 to 9999 seconds
(30)
0 is off. Does not
appear in Pb-n =
0.0%
Return to “CSet” to program other Control Points if desired.
-55-
QUICK REFERENCE TABLE: CONFIGURATION CONTROL POINT MODULE 7 (7-CP)
