HIDDEN FUNCTION MODE
The Hidden Function Mode is only accessible from
the normal display mode by pressing and holding the
PAR button for three seconds. In this mode, five
controller functions can be performed.
Automatic/Manual Transfer
Initiate/Cancel Auto-tune
Reset Alarm/Timed Event Output(s)
Load Control Point
Control Profile Status
Each function may be “locked out” in the
configuration parameter lockouts module. The PAR
button is used to scroll to the desired function and the
up and down buttons are used to select the operation.
Pressing the PAR button while the function is
displayed executes the function and returns the unit to
the normal display mode. Pressing the DSP button
exits this mode with no action taken. The unit
automatically returns to the normal display mode if a
function is not executed in eight seconds.
-28-
Display Parameter
Range and Units
(Factory Setting Value)
Description/Comments
CP Load Control Point NO
cp-1
cp-2
cp-3
cp-4
(NO)
This step does not appear if locked (LOC). Exits
to normal display mode if executed. Select
control point to load then press PAR to
implement.
PruN Control profile
status
Pr-1
Pr-2
Pr-3
Pr-4
(OFF)
This step does not appear if locked (LOC), or
profile is running.
Exits to normal display mode if executed. Select
profile to start, then press PAR button.
Adnc
Cont
PAUS
OFF
(Cont)
This step does not appear if locked (LOC), or
profile is in OFF mode.
If profile is running, select control mode, then
press PAR button.
trnF Transfer mode of
operation
Auto - Automatic control
User - Manual control (Auto)
This step does not appear if locked (LOC). Exits
to normal display mode if executed.
tUNE Auto-Tune
invocation
YES/NO (NO) Yes: starts /restarts auto-tune sequence.
No: terminates auto-tune sequence.This step
does not appear if locked (LOC) or exits to
normal display mode if executed.
ALrS Reset alarm/timed
event output(s)
UP key resets Alarm 1/event
output 1
DOWN key resets Alarm
2/event output 2
This step does not appear if alarm option not
installed, if locked (LOC) or previous step
performed.
Hidden Function Mode Reference Table
