Red Lion TSC - Manual (Page 53)

Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
SP Setpoint access LOC - lockout
rEd - read only
Ent - enter
(Ent)
Allows access to
temperature
setpoint
OP Output power
access
LOC - lockout
rEd - read only
Ent - enter
(Ent)
Allows direct
access to output
power. %PW
indicator illuminates
when parameter is
selected in display.
P-CS Profile status
display
LOC - lockout
rEd - read only
Ent - enter
(rEd)
Allows access to
profile status. PGM
indicator illuminates
when parameter is
selected in display.
P-tr Profile time
remaining
LOC - lockout
rEd - read only
Ent - enter
(rEd)
Allows access to
phase time
remaining. PGM
indicator illuminates
when parameter is
selected in display
UdSP Units display LOC - lockout
rEd - read only
Ent - enter
(rEd)
Allows display of °F
or °C
Code Access code 0 to 250
(0)
Refer to front panel
disable section for
access levels.
PId PID values enable LOC - lockout
rEd - read only
Ent - enter
(LOC)
Protected mode
lockout
AL Alarm values
enable
LOC - lockout
rEd - read only
Ent - enter
(LOC)
Protected mode
lockout
ALrS Reset alarm/timed
event outputs
enable
LOC - lockout
ENBL - enable
(LOC)
Hidden mode
lockout
Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
CPAC Control point
access
LOC - lockout
ENBL - enable
(LOC)
Hidden mode
lockout
PrAC Ramp/hold profile
access
LOC - lockout
ENBL - enable
(LOC)
Hidden mode
lockout
trnF Automatic / Manual
(user) transfer
enable
LOC - lockout
ENBL - enable
(LOC)
Hidden mode
lockout
tuNE Auto-tune enable LOC - lockout
ENBL - enable
(LOC)
Hidden mode
lockout
-51-
QUICK REFERENCE TABLE: CONFIGURATION LOCKOUT MODULE 3 (3-LC)
