Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
bAUd Baud rate 300 to 9600
(1200)
Baud rate of unit must
match other equipment.
PArb Parity bit odd, even, no parity
(odd)
Parity of unit must
match other equipment.
Add Unit address 0 to 99
(0)
For multiple units,
each unit must have a
unique address.
Abr Abbreviated or full
transmission
yes/no
(no)
Selecting yes, the
controller does NOT
transmit mnemonics.
PrAt Auto print rate 0 to 9999
(0)
0 disables auto print
function
PoPt Print options Yes/no (no) Selecting yes allows
print options to be
programmed.
INP Input Temperature Yes/no (yes)
SEt Setpoint Yes/no (yes)
OPr % Output Power Yes/no (yes)
Pdb % Proportional Band Yes/no (no)
INt Integral Time Yes/no (no)
dEr Derivative Time Yes/no (no)
AL1 Alarm 1 Yes/no (no)
AL2 Alarm 2 Yes/no (no)
dEv Deviation From Setpoint Yes/no (no)
OFP % Output Power Offset Yes/no (no)
r-P Setpoint Ramp Rate Yes/no (no)
Crg Cooling Relative Gain Yes/no (no)
Cdb Cooling Deadband Yes/no (no)
P-t Profile Phase Time
Remaining
Yes/no (no)
P-S Profile Operation Status Yes/no (no)
-54-
QUICK REFERENCE TABLE: CONFIGURATION SERIAL COMMUNICATIONS MODULE 6 (6-SC)
Unit returns to configuration access point if RS-485 serial option is not installed.
