APPENDIX “F” - USER PARAMETER VALUE CHART (Cont’d)
Configure Control Points
Mnemonic Parameter User Setting
CP-1 CP-2 CP-3 CP-4
SP Setpoint Value
PID YES/NO Load With
Setpoint Value
Pb Proportional Band
It Integral Time
dt Derivative Time
Configure Profiles
Mnemonic Parameter
Pr-1 Pr-2 Pr-3 Pr-4
PnCC Profile Cycle Count
Pnln Profile Link
PnSt Profile Status
PnEb Profile Error Band
Pnr1 Profile Ramp Rate 1
Pnl1 Profile Setpoint Level 1
PnH1 Profile Hold Time 1
Pnr2 Profile Ramp Rate 2
Pnl2 Profile Setpoint Level 2
PnH2 Profile Hold Time 2
Pnr3 Profile Ramp Rate 3
Pnl3 Profile Setpoint Level 3
PnH3 Profile Hold Time 3
Pnr4 Profile Ramp Rate 4
Pnl4 Profile Setpoint Level 4
PnH4 Profile Hold Time 4
Pnr5 Profile Ramp Rate 5
Pnl5 Profile Setpoint Level 5
PnH5 Profile Hold Time 5
Pnr6 Profile Ramp Rate 6
Pnl6 Profile Setpoint Level 6
Mnemonic Parameter User Setting
Pr-1 Pr-2 Pr-3 Pr-4
PnH6 Profile Hold Time 6
Pnr7 Profile Ramp Rate 7
Pnl7 Profile Setpoint Level 7
PnH7 Profile Hold Time 7
Pnr8 Profile Ramp Rate 8
Pnl8 Profile Setpoint Level 8
PnH8 Profile Hold Time 8
Configure Timed Event
Outputs PE-1 PE-2 PE-3 PE-4
Pn 1 Event 1
Pn 2 Event 2
Pn 3 Event 3
Pn 4 Event 4
Pn 5 Event 5
Pn 6 Event 6
Pn 7 Event 7
Pn 8 Event 8
Pn 9 Event 9
Pn 10 Event 10
Pn 11 Event 11
Pn 12 Event 12
Pn 13 Event 13
Pn 14 Event 14
Pn 15 Event 15
Pn 16 Event 16
Controller Operating Mode
Automatic or Manual
Auto-Tune Invoked at
