Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
CYCt Cycle time 0 to 120 seconds
(2)
0 turns OP1 off.
OPAC Control action drct - cooling
rEv - heating
(rev)
For both PID &
ON/OFF control.
OPLO Output power lower
limit range
0% to 100%, OP1
-100% to 100%,
OP1 & OP2
(0, no cooling)
(-100, cooling)
Set OPLO < OPHI
If cooling option is
installed.
OPHI Output power upper
limit range
0% to 100%, OP1
-100% to 100%,
OP1 & OP2
(100)
Set OPHI > OPLO
If cooling option is
installed.
OPFL Sensor fail power
preset
0% to 100%, OP1
-100% to 100%,
OP1 & OP2
(0)
Set to a value to safely
control the process in
the event of input
sensor failure.
CHYS ON/OFF control
hysteresis
1 to 250
1 or 0.1 degree
(1)
Heating side only.
tcod Auto-tune damping
code
0 to 4
(0)
0 = fastest response
4 = slowest response
ANAS Linear DC output
assignment
OP - % output power
INP - input temp.
SP - setpoint value
dEv - deviation
(OP)
This parameter does
not appear if analog
option is not installed.
ANLO Linear DC output low
scaling value
-999 to 9999
(0.0)
Units depend on ANAS
selection. This
parameter does not
appear if analog option
is not installed.
ANHI Linear DC output high
scaling value
-999 to 9999
(100.0)
Units depend on ANAS
selection. This
parameter does not
appear if analog option
is not installed.
-50-
QUICK REFERENCE TABLE: CONFIGURATION OUTPUT MODULE 2 (2-OP)
