Red Lion TSC - Manual (Page 51)

Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
tYPE Input type tc-t - Type T TC
tc-E -Type E TC
tc-J - Type J TC
tc-k - Type K TC
tc-r - Type R TC
tc-S - Type S TC
tc-B - Type B TC
tc-N - Type N TC
LIN - Linear mV display
If changed, check PID
settings and input select
jumper position. (jumper in
TC position)
r385 - 385 curve RTD
r392 - 392 curve RTD
rLIN - Linear ohms display
(tc-J)
(jumper in RTD position)
SCAL Temperature
scale
°F/°C
(°F)
If scale is changed, all
parameters must be
checked.
dCPt Temperature
resolution
0 or 0.0
(0)
If resolution changed, all
parameters must be
checked.
FLtr Digital filtering for
input signal
0 to 3
(1)
Increase number for more
filtering effect.
SPAN Input signal slope
(correction factor)
0.001 to 9.999
(1.000)
Normally set to 1.000
SHFt Input signal offset
(correction shift)
-999 to 9999
1 or 0.1 degree
(0)
Normally set to 0
SPLO Lower limit
setpoint range
-999 to 9999
1 or 0.1 degree
(0)
Set low limit below high
limit.
SPHI Upper limit
setpoint range
-999 to 9999
1 or 0.1 degree
(9999)
Set high limit above low
limit.
Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
SPrP Setpoint ramp rate 0.0 to 999.9
degrees/minute
(0.0)
0.0 is off (no auto
ramping)
(Not related to profile
operation.)
InPt User input PLOC - Program disable
ILOC - Integral action
on/off
trnF - Auto/manual transfer
SPrP - Ramp rate on/off
ALrS - Reset alarm
output(s)
Prnt - Print request
CP - Control point load
P1rH - Run/pause a profile
or start profile 1
P1rS - Profile 1 stop/restart
(PLOC)
-49-
QUICK REFERENCE TABLE: CONFIGURATION INPUT MODULE 1 (1-IN)
