-85-
APPENDIX “F” - USER PARAMETER VALUE CHART
Unit Number
Mnemonic
Parameter
User Setting
SP
Temperature Setpoint
OPOF
Output Power Offset
OP
Output Power
ProP
Proportional Band
Intt
Integral Time
dErt
Derivative Time
AL-1
Alarm 1
AL-2
Alarm 2
Configure Input
tYPE
Input Sensor Type
SCAL
Temperature Scale Units
dCPt
Temperature Resolution
FLtr
Digital Filtering
SPAN
Input Slope
SHFt
Input Offset
SPLO
Setpoint Lower Limit
SPHI
Setpoint Upper Limit
SPrP
Auto Ramp Rate
InPt
User Input
Configure Output
CYCt
Cycle Time
OPAC
Control Action
OPLO
Output Power Lower
Limit Range
OPHI
Output Power Upper
Limit Range
OPFL
Sensor Fail Power Preset
CHYS
ON/OFF Control Hysteresis
tcod
Auto-Tune Damping Code
ANAS
Linear Output Assignment
ANLO
Linear Output Scale Value
ANHI
Linear Output Scale Value
Configure Lockouts
Mnemonic
Parameter
User Setting
SP
Access Setpoint
OP
Access Output Power
P-cs
Access Profile Status
P-tr
Access Time Remaining
UdSP
Access Display Units
Code
Access Code Number
PID
Access PID Values
AL
Access Alarm(s) Values
ALrS
Enable Reset Alarm(s)
CPAC
Enable Control Points
PrAC
Enable Profile Status
trnF
Enable Auto/Man Transfer
tUNE
Enable Auto-Tune
Configure Alarms
Act1
Alarm 1 Operation Mode
rSt1
Alarm 1 Reset Mode
Stb1
Alarm 1 Standby Enabled
AL-1
Alarm 1 Value
Act2
Alarm 2 Operation Mode
rSt2
Alarm 2 Reset Mode
Stb2
Alarm 2 Standby Enabled
AL-1
Alarm 2 Value
AHYS
Alarm Hysteresis Value
Configure Cooling
CYC2
OP2 Output Cycle Time
GAN2
Relative Cooling Gain
db-2
Heat-Cool Overlap/Deadband
Configure Serial Communications
Mnemonic
Parameter
User Setting
bAUd
Baud Rate
PArb
Parity Bit
Addr
Unit Address
Abrv
Abbrev. or Full Transmission
PrAt
Automatic Print Rate
PoPt
Print Options
INP
SEt
OPr
Pdb
INt
dEr
AL1
AL2
dEv
OFP
r P
Crg
Cdb
P-t
P-s
