INSTALLATION
Always wear adequate safety equipment when performing any maintenance
or repair work.
The tractor symbol on the shield indicates the tractor end of the driveline.
Torque limiters or overrunning clutches must be mounted at the implement
end.
Ensure that the driveline is securely attached to the tractor and the imple-
ment before operating.
Check that all bolts or nuts are properly torqued.
Attach the shield restraint chains, allowing sufficient slack for the driveline to
move during turns and operation.
Best results are achieved when the chains are attached nearly perpindicular to the
driveline guard. Adjust the length to allow articulation of the driveline in working or
transport postions, but avoid excessive slack that may wrap around the driveline.
If the length of the chain is not adjusted correctly and tension is excessive,
for example during machine maneuvers, the “S” connection hook will open
and the chain will disconnect from the shield.
In this case, replace the chain.
The “S” hook of the new chain must be inserted in the eyelet of the base cone and
must be closed to prevent it slipping and maintain its form.
If the length of chain is not adjusted correctly and tension is excessive, for
example during machine maneuvers, the “Spring Link” connection will open
and the chain will disconnect from the shield.
The chain may be easily reconnected as described in the following procedure.
Open the locking ring by loosening the screw and removing the plate.
Insert the chain in the locking ring and reposition the plate.
Close the plate by means of the screw.
Never use the shield restraint chains to support the driveline for storage.
Always use the support on the implement.
17
18
19
20
21
23
24
25
22
540 min
-1
1000 min
-1
Pn
Mn
Pn
Mn
kW
CV-HP-PS
N∙m
kW
CV-HP-PS
N∙m
S1
13
18
234
20
27
190
S2
21
28
364
31
42
295
S4
28
38
494
42
57
400
S5
37
50
651
55
75
527
S6
40
55
716
61
83
583
H7
51
70
911
78
106
745
S8
66
90
1171
100
136
956
H8
66
90
1171
100
136
956
S9
81
110
1431
122
166
1166
SH
97
132
1717
147
200
1405
S0
124
169
2199
187
254
1785
SK
180
254
3183
284
386
2712
RATED POWER Pn and RATED TORQUE Mn
