Chapter 4 _________________________________________________________________ Operation
VAISALA ________________________________________________________________________ 95
Table 22 Data Recording Commands
Command Description
DIR Display recorded files
PLAY [0 ... 28] [START END] Output recorded data file. Start and end times
can only be specified if the data logger module
is installed. The times must be given in the
following format:
yyyy-mm-dd hh:mm:ss
DSEL Select data recording and display quantities
(1 ... 4).
DELETE Delete all data files, including the memory of
the optional data logger module
UNDELETE Recover the deleted files that have not been
overwritten
Table 23 Chemical Purge Commands
Command Description
PUR Set the automatic chemical purge
PURGE Start the manual chemical purge
RGLIMIT [ON/OFF] Prevent chemical purge if sensor temperature
is below 0 °C
Table 24 Calibration and Adjustment Commands
Command Description
CRH Relative humidity calibration
CT Temperature calibration
CTA Additional temperature probe calibration
FCRH Relative humidity calibration after sensor
change
CTEXT Give the text to calibration information field
CDATE Set the calibration date
ACAL Analog output calibration
LC Output the linear corrections in use
LCI [ON/OFF] Activate or deactivate the linear offset or
offset/gain pressure corrections
LCI Enter new linear offset and offset/gain pressure
corrections to the transmitter
MPC Output the multipoint corrections in use for
pressure measurement
MPCI [ON/OFF] Activate or deactivate the multipoint corrections
for pressure measurement
MPCI Enter new multipoint corrections for pressure
measurement
MPC RH
[ON/OFF/LIST/INIT/CLEAR] Multipoint correction for relative humidity
OFFSET Pressure one-point offset correction
Table 25 Setting and Testing the Analog Outputs
Command Description
AMODE View the analog output modes
ASEL Select the parameters for the analog outputs
ITEST Test the analog outputs
