Chapter 4 _________________________________________________________________ Operation
VAISALA _______________________________________________________________________ 101
General Settings
Changing Quantities and Units
Use serial commands or the optional display/keypad to change quantities
and units. For more information on available quantities and units, see
Table 4 on page 22. For more information on optional quantities, see
Table 5 on page 22.
NOTE
Only the quantities selected when ordering the device can be selected as
display output quantities.
Using Display/Keypad
To select the display output quantities.
1.
Press any of the arrow buttons to open the Main Menu.
2.
Select Display, press the right arrow button.
3.
Select Quantities, press the right arrow button.
4.
Select quantities by pressing the up/down arrow buttons. Confirm
the selection by pressing the SELECT key. You can select 1 ... 4
display quantities at a time.
5.
Press the EXIT key to return to the basic display.
To select the display unit:
1.
Press any of the arrow buttons to open the Main Menu.
2.
Select Display, press the right arrow button.
3.
Select Units and press the right arrow button.
4.
Select the display unit by pressing the up/down arrow buttons.
Confirm the selection by pressing the CHANGE key. The unit
changes from metric to non-metric or the other way round.
5.
Press the EXIT key to return to the basic display.
NOTE
Changing the display quantities/units (by using the display/keypad) has
no effect on the serial output data.
Using Serial Line
FORM
Use the serial line command FORM to change the format or select a
certain quantities for the output commands SEND and R.
FORM [x]
