User's Guide _______________________________________________________________________
186 __________________________________________________________________ M210796EN-G
Mechanics
Cable bushing M20x1.5 For cable diameter
8 ... 11mm/0.31 ... 0.43"
Conduit fitting 1/2”NPT
User cable connector (optional) M12 series 8- pin (male)
option 1 with plug (female) with 5 m /
16.4 ft black cable
option 2 with plug (female) with screw
terminals
Probe cable diameter
PTU303 80ºC 6.0 mm
Other probes 5.5 mm
Probe tube material
PTU301 Chromed ABS plastic
Other probes AISI 316L
Housing material G-AlSi 10 Mg (DIN 1725)
Housing classification
Without display IP 66 (NEMA 4X)
With display and keypad IP 65 (NEMA 4X)
Transmitter weight (with probe, cable, and modules) 1.0 ... 3.0 kg (2.2 ... 6.6 lb)
Table 41
Standard Probe Cable Lengths and Approximate
Transmitter Weight (in kg/lb)
Probe Type Probe Cable Length
2 m
5 m 10 m 20 m
PTU303 1.1/2.4 1.2/2.6 1.5/3.3 2.1/4.5
PTU307 1.2/2.6 1.3/2.9 1.5/3.3 2.1/4.5
