Appendix A __________________________________ Probe installation kits and installation examples
VAISALA _______________________________________________________________________ 199
Examples of Vapor Tight Installations with
Cable Gland
RH-Probe Installations (for PTU303/307)
Cable gland AGRO is available from Vaisala (order code: HMP247CG.)
0508-026
Figure 90
Cable Installation with Cable Gland
The following numbers refer to Figure 90 above
1
=
Nut (to be tightened to the body)
2
=
Seal
3
=
Body and O-ring
1
3
2
