PF3000 Pro Cotton Yield Monitor
Marking Ag Leader Technology
July 2003 4-8
Introduction
You must have a GPS receiver and memory card to do field marking. To
perform field marking you can use the internal marker selection keys built
into the PF3000 Pro Cotton Yield Monitor to identify the 4 marks available
or connect the external field marker device. You can not use both at the
same time. You can make marks in all operating modes of the PF3000 Pro
Cotton Yield Monitor.
IMPORTANT: Make sure that under the CONSOLE setup key, you
have the Field Marker set correctly to either INTERNAL or
EXTERNAL.
If you are using the internal marks, you can rename the marks and also set
them up as a continuous or spot mark. If you are using the external Field
Marker, you can not rename the marks but can do continuous or spot
marking.
Continuous marking
Making several marks in a row (for example: marking large weed
patches or tile lines).
Spot marking
Marking just one mark (for example: marking a rock or tile hole).
Setting Up Marks
Press the SETUP key and MARKS key to display the marker setup screen
and name and set the internal marks. If you are using the external Field
Marker, you do not need to make any settings on the Marker Setup screen.
Making Marks You can mark more than one item at a time. When a mark is turned on the
monitor will beep and the mark will flash.
Follow the steps below to make marks when using the internal marks.
Step Action
1 Display FIELD, LOAD, MARKS on the bottom by pressing the
MENU key .
