System Wiring PF 3000 Pro
Ag Leader Technology
March 1999 7-12
Signal PF3000 Pro Cab / Distrib. Power Ground Spd Fan Spd Flow Header
Rectangular Round Rectangular Rectangular Rectangular Round Rectangular Radar
25 pin 24 pin 3 pin 2-pin 2 pin 4 pin 3 pin 4-pin
Power (14V)(US) 1 1 A
RS(485C) 2 -
RS(485A) 3 2 4
Moist2 (-) 4 3
Temp 5 4
SP1 6 5 A
SP2 7 6 A
A5V 8 7
QMinus 9 8
GND 10 9 C 1
Vcc (+5V) 11 10 A
D12V 12 11 3
Power (14V)(S) 13 12 1
RS(485B) 14 13 3
15 -
Moist1 (+) 16 14
Field Marker 17 15
HDR 18 16 B
SP3 19 17 B
SP4 20 18 B 2
QPlus 21 19
AGND 22 20
GND 23 21
Vcc (+5V) 24 22
GND 25 23 C 2
Drain shell 24
