PF3000 Pro Cotton Yield Monitor
Swath Setup Ag Leader Technology
July 2003 2-16
Changing a Setting Step Action
1 Use the UP or DOWN ARROW keys to select type of spacing to
be set.
2 Press the EDIT key to change the spacing. Use the UP or DOWN
ARROW keys to change the number. Press the ACCEPT key after
you have changed the number.
3 Press the EXIT key once you have made all the settings.
Full Swath Adjustable in 1 inch increments. The range of settings is from 30 to 500
inches. Set the full swath in the monitor to the full swath of your header.
For broadcast headers it is advisable to set the swath to 6” to 12” less than
the actual swath width of the header because you can rarely maintain a full
swath while harvesting. In some cases, the number of rows the header can
harvest will exceed the limit of the monitor. If this happens, the full swath
is what you should be concerned with. It does not matter if the number of
rows or the width of each row in the monitor does not exactly match your
true situation.
Row to Row
Spacing Selecting this option changes the line selected to only highlighting the
spacing value. The UP or DOWN ARROW keys will adjust the value by
whole number increments. When swath is edited, all row spacings become
equal to the full swath divided by the number of rows. The default is 40
inches. The limits are from 10 to 100.
Row 1 to Vehicle
Center Adjustable in 1 inch increments. Limits are from 0 to full swath value.
This accounts for offset headers.
Refer to the Swath Setting instructions in the Operation Section for more
information about partial swath.
* * *
