PF3000 Pro Cotton Yield Monitor
Ag Leader Technology GPS Setup
July 2003 2-29
Introduction The integrated GPS of the PF3000 Pro Cotton Yield Monitor requires no
initial setup to begin fieldwork. The PF3000 Pro Cotton Yield Monitor
will display a “D” or “G” on the top right hand corner of the display to
indicate a GPS signal. A “D” indicates that you have a differential signal.
A “G” indicates that you have a GPS signal and you GPS receiver are
tracking four or more satellites. A lower case “g” indicates that you have
a GPS signal but your GPS receiver is tracking only three satellites. Your
GPS receiver must track four or more satellites to get an elevation
reading. You may wish to use the GPS to show your ground speed,
which requires changing the ground speed sensor settings. Refer to
Primary and Secondary Speed Sensor under Vehicle Setup in the PF3000
Pro Cotton Yield Monitor Operator’s manual for instructions.
The following provides information to change factory settings on the
integrated GPS:
Beacon Selection The settings for beacon selection are Auto range, Auto Power and
Manual.
•
Auto Range: This is the default setting. In this setting the receiver
keeps a record of the closest three beacons within the receivers range.
It then selects a beacon based on the ranking of the beacon in memory.
•
Auto Power: The receiver keeps a record of the three strongest
beacons in its range. It then selects a beacon based on the ranking of
the available beacons.
•
Manual: Allows you to input frequencies for two beacons.
To change Beacon Selection complete the following steps:
Step Action
1 Press Menu key on PF3000 until SETUP is displayed and
press SETUP.
2 Press bottom left or right arrow key until GPS is
displayed and press GPS key.
