PF3000 Pro Cotton Yield Monitor
Ag Leader Technology System Wiring
July 2003 7-9
Pin-Out of AUX Port 1
(Pro w/ GPS) Pin Number Name Remarks
1 Event
2 PORT_B_ OUT
3 PORT_B_IN
4 PWR_CTL
5 GND
6 GPS_RTS_B
7
8 GPS_CTS_B
9 PWR_OUT
10 PWR_Out_12V
11 GND
12 PPS
13 RS232-TX
14 RS232-RX
15
Pin-Out of AUX Port 1
(Pro w/o GPS) Pin Number Name Remarks
1 --
2 -- * Pro w/o GPS has this pin
jumpered to RS232-Rx Port D
3 -- * Pro w/o GPS has this pin
jumpered to RS232-Tx Port D
4 --
5 Ground
6 --
7 --
8 --
9 --
10 Relay Power Out (Controlled by
monitor power)
11 Ground
12 --
13 RS232-Tx Port D (Used for GPS)
14 RS232-Rx Port D (Used for GPS)
15 --
