PF3000 Pro Cotton Yield Monitor
Ag Leader Technology System Wiring
July 2003 7-7
System Wiring Refer to the last page to see a table of the pin-outs of the machine cables for
the PF3000 Pro Cotton Yield Monitor.
Pin-Out of Port 1
This connector may be used by: Controller #3, a Bar Code device, TBD RS-
232 device or connection to a PC.
Pin Number Name Remarks
1
2 RXC
3 TXC
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9
