PF3000 Pro Cotton Yield Monitor
Troubleshooting Ag Leader Technology
July 2003 6-6
Problem Cause Solution
AREA OFF Always
Displayed NOTE:
The AREA ON must be
displayed to count
acres. Area count switch is
in down position. Area count switch must be up to make AREA ON
appear on the screen.
Stop height number is
set too high. Press MENU, CAL, STOP HGT and ENTER
HEIGHT to display stop height setting. Adjust
stop height so that when the head is raised AREA
OFF appears on the screen.
Header sensor
installed backwards. Refer to Installation Instruction. Ensure header
sensor is installed in the correct place with the
correct orientation (cable toward the rear of
machine, open end of black header sensor bracket
pointing towards ground).
Header sensor set to
OPTIONAL solution. Set to STANDARD under vehicle setup. NOTE:
The Optional setting is not used at this time.
Cable connections are
bad. Disconnect cab and distribution cables and inspect
pins for corrosion. Inspect the cables for cuts or
pinches. Reconnect cables and check area.
Header sensor bad. Check resistance of the header sensor between
pins, A, B, and C on header sensor cable. Refer to
Reference Section for correct resistance readings.
Monitor Chirps
While Harvesting Monitor is set on a
partial swath. Display SWATH on the screen. Use the up/down
arrow keys to adjust to a full swath.
When you have Fan Speed but are not recording
area.
If Continuous Marks was left on.
Incorrect Distance
and MPH Calibration for
distance is incorrect
or has not been done. Refer to "Calibrating Distance" in Calibration
Section.
After you calibrate for distance, the monitor
automatically corrects any incorrect distance and
acres for previously harvested loads. NOTE: You
must calibrate the secondary speed sensor setting
if GPS is the primary speed sensor.
Monitor is set on the
incorrect ground-
speed setting. Press MENU, SETUP, and VEHICLE to display
Primary Speed Sensor. Use up/down arrow keys
to correct the speed setting. If loads were set to the
incorrect setting, change the loads to correct speed
setting and the monitor will automatically correct
acres and distance.
