PF 3000 Pro Cotton Yield Monitor
Installation Ag Leader Technology
July 2003 9-2
Installing
Antenna
Follow these steps to install the antenna:
Step Action
1 Center the antenna on the top the top surface of the bracket,
placing the antenna so the cable connector is pointing
towards the right side of machine or vehicle.
2 Attach the 15 ft cable to antenna, connecting the end with
the plug to antenna.
3 Attach a white cable tie-down to metal surface 1 or 2 ft
below and 6 in. to right of the L-bracket.
NOTE: you may need to increase the above distances,
depending on the type of cotton extension you are using.
4 Place another white tie-down 3 to 5 ft. to the right of the
first tie-down.
5 Use a cable tie and attach the coaxial cable to the first
white tie-down leaving some slack in cable between
antenna connection and tie down to allow for strain relief if
the antenna is knocked off the L-bracket.
6 Use another cable tie to attach the cable to the second tie-
down.
7 Route cable to cab using cable tie-downs to secure cable.
