FC1 FC2 GE1 GE2
MGMT HP StorageWorks mpx100 IOIOI
! FC1 FC2 GE1 GE2
MGMT HP StorageWorks mpx100 IOIOI
!
GE1
MGMT
FC1 FC2 GE1
MGMT
FC1 FC2 GE2 GE2
26381b
D1
D4
D3
D2
Discovery
IP Address
Presented
iSCSI Targets
D1 FP1A
FP1B
FP1A
FP1B
D2
FP1A
FP1B
FP1A
D3
D4
FP1B
IP Network
management
(WAN/LAN)
iSCSI
NIC
Command
View EVA
IP Network
iSCSI data
(LAN/VLAN)
EVA4400
Storage System
mpx100/100b 1 mpx100/100b 2
A B
Figure 2 EVA4400 direct connect iSCSI-Fibre Channel attachment mode configuration
Figure 3
and Figure 4 illustrate the HP Command View EVA iSCSI deployment configurations. These
configurations are used with EVA 4000/4100/4400/6x00/8x00 storage systems and allow for HP
Command View connectivity without the need for a Fibre Channel switch. Figure 4 shows a redundant
configuration using two mps100/100b's.
FC1 FC2 GE1 GE2
MGMT HP StorageWorks mpx100 IOIOI
!
26484a
D1
GE1
MGMT
Discovery
IP address
Presented
iSCSI targets
D1 FP1B
FP1A
IP network
management
(WAN/LAN)
IP network
iSCSI data
(LAN/VLAN)
FC1 FC2
NIC
mpx100/100b
iSCSI initiator &
Command View
EVA server
EVA
Storage System
Figure 3 HP Command View EVA deployment configuration 1
EVA iSCSI connectivity user guide 23
