Menu item

Values

Description

STAPLES OUT

CONTINUE

STOP

The STAPLES OUT menu defines the
action that the stapler/stacker takes when it
runs out of staples. It can instruct the printer
to stop and wait until the stapler cartridge is
replaced, or it can allow printing to continue
without stapling. If the device is configured
to stop when the cartridge is empty, up to
two jobs might be processed without
stapling before the printer stops. The
default is CONTINUE.

OFFSET

ENABLED

DISABLED

The OFFSET menu stipulates whether the
job should be offset. When this
configuration is set at the control panel, it is
applied to all subsequent jobs. It cannot be
applied on a job-by-job basis. The default is
ENABLED.

Only supported paper sizes can be offset.

I/O menu

This menu allows you to configure the printer’s I/O options.

See

Network configuration

.

Menu item

Values

Description

I/O TIMEOUT

15 SECONDS

Range:5 - 300

Allows you to set the printer I/O timeout in
seconds.

PARALLEL INPUT

HIGH SPEED

ADVANCED FUNCTIONS

Allows you to select the speed at which the
parallel port communicates with the host
and to enable or disable the bi-directional
parallel communication.

The default for HIGH SPEED is YES. The
default for ADVANCED FUNCTIONS is
ON.

EMBEDDED JETDIRECT MENU

The values may vary. Possible
values may include:

TCP/IP

IPX/SPX

APPLETALK

DLC/LLC

SECURE WEB

DIAGNOSTICS

RESET SECURITY

LINK SPEED

TCP/IP: Select whether the TCP/IP
protocol stack is enabled or disabled. You
can set several parameters.

Select the TCP/IP CONFIGURE
METHOD
to configure the EIO card. For the
MANUAL option, select the values for IP
ADDRESS
, SUBNET MASK, LOCAL
GATEWAY
, and DEFAULT GATEWAY.

IPX/SPX: Select whether the IPX/SPX
protocol stack (in Novell NetWare
networks, for example) is enabled or
disabled.

APPLETALK: Enable or disable an
AppleTalk network.
