control(5)
controlLight(1)
■controlLightNumEntries(1)[INTEGER]
controlLightTable(2)
controlLightTableEntEntry(1)
controlLightDeviceColor(1)[INTEGER]
controlLightControlState(2)[INTEGER]
controlLightControlTimer(3)[INTEGER]
controlLightCurrentState(4)[INTEGER]
controlLightSnmpClear(3)[INTEGER]
trap(6)
■trapPatliteAlarmAdded(1)[OBJECT IDENTIFIER]
■trapPatliteAlarmRemoved(2)[OBJECT IDENTIFIER]
■trapPatliteTrapReceived(3)[OBJECT IDENTIFIER]
■trapPatliteClearExecuted(4)[OBJECT IDENTIFIER]
■trapPatliteRshExecuted(5)[OBJECT IDENTIFIER]
■trapPatliteAppMonitorAlarmAdded(6)[OBJECT IDENTIFIER]
■trapPatliteAppMonitorAlarmRemoved(7)[OBJECT IDENTIFIER]
■trapPatliteTestSwExecuted(8)[OBJECT IDENTIFIER]
5.2 PATLITE MIB SPECIFICATIONS
The following explains the MIB Specification for the NH Series Monitoring Tower.
iso(1)
org(3)
dod(6)
internet(1)
private(4)
enterprises(1)
patlite(20440)
patliteModule(4)
networkSignalTower(1)
config(2)
alarm(3)
monitor(4)
control(5)
trap(6)
ident(1)
