3.4.1 SNMP SET Control Function for Signal-Tower
The Signal Tower and buzzer are controllable through the SNMPSET command.
The following is an example to control the “on” and ”off” for the Signal Tower lighting and buzzer.
[Application Example 1] Turning the red unit on. Set it up as followed:
Object Object ID Value
controlLightControlState 1.3.6.1.4.1.20440.4.1.5.1.2.1.2.1 2
controlLightControlTimer 1.3.6.1.4.1.20440.4.1.5.1.2.1.3.1 0
[Application Example 2] Operating the flashing pattern1 for the amber unit. Set it up as followed:
Object Object ID Value
controlLightControlState 1.3.6.1.4.1.20440.4.1.5.1.2.1.2.2 3
controlLightControlTimer 1.3.6.1.4.1.20440.4.1.5.1.2.1.3.2 0
[Application Example 3] With the red unit flashing pattern2, and amber flashing pattern1, after 5 seconds,
the green turns on with the buzzer synchronized with light pattern2. Set it up as
followed:
Object Object ID Value
controlLightControlState 1.3.6.1.4.1.20440.4.1.5.1.2.1.2.1 5
controlLightControlTimer 1.3.6.1.4.1.20440.4.1.5.1.2.1.3.1 0
controlLightControlState 1.3.6.1.4.1.20440.4.1.5.1.2.1.2.2 3
controlLightControlTimer 1.3.6.1.4.1.20440.4.1.5.1.2.1.3.2 0
controlLightControlState 1.3.6.1.4.1.20440.4.1.5.1.2.1.2.3 2
controlLightControlTimer 1.3.6.1.4.1.20440.4.1.5.1.2.1.3.3 5
controlLightControlState 1.3.6.1.4.1.20440.4.1.5.1.2.1.2.6 3
controlLightControlTimer 1.3.6.1.4.1.20440.4.1.5.1.2.1.3.6 0
3.4.2 SNMP GET Status Acquisition Function for Signal-Tower
The Signal Tower status is acquisitioned through the SNMP GET command. The following is an example of a
Signal Tower status acquisition.
[Application Example 1] The red is lighting, the amber is flashing pattern1, green is off, blue is flashing
pattern2 and white is on. The buzzer sound pattern3 is an example of
acquisitioning the Signal Tower status.
Object Object ID GET Value
controlLightCurrentState 1.3.6.1.4.1.20440.4.1.5.1.2.1.4.1 2
controlLightCurrentState 1.3.6.1.4.1.20440.4.1.5.1.2.1.4.2 3
controlLightCurrentState 1.3.6.1.4.1.20440.4.1.5.1.2.1.4.3 1
controlLightCurrentState 1.3.6.1.4.1.20440.4.1.5.1.2.1.4.4 4
controlLightCurrentState 1.3.6.1.4.1.20440.4.1.5.1.2.1.4.5 2
controlLightCurrentState 1.3.6.1.4.1.20440.4.1.5.1.2.1.4.6 4
3.4.3 TRAP Reception Function
With the set-up containing the designated sender or with the OID included, the TRAP is received. When
the TRAP transmission is sent, the information, e-mail transmission and time of reception according to the
Signal Tower can be included. For further details on the setting method, refer to “4.9 TRAP Reception Setting
Screen”.
3.4.4 TRAP Transmission Function
The TRAP is sent to the designated sender when the TRAP Reception setup for this product is done. For
further details on the setting method, refer to “4.4 The SNMP Configuration Screen”.
Please Set the community name for the TRAP transmission of this product to "public."
