4.8 RSH Command Setup Screen
RSH (remote shell) Commands can control the Signal Tower and buzzer on this product.
The following explains the setup to be able to receive the RSH Commands.
[Setup Method]
RSH Server Function
1. When receiving the RSH Commands, first turn on the RSH Server function by selecting "Active."
RSH Alert Timer Reset Function
2. A timer can be implemented to control the operating timing of each tier and the buzzer with an RSH
command sent to the Signal Tower.
If the "Shared" function is selected, the timing control for each color can be in common.
If the "Separate" function is selected, the timing control for each color is controlled individually.
E-mail Transmission
3. To have E-mail Sending when an RSH Command has been received, and for it to make a report, select
"Active".
Select "Inactive" to prevent any E-mail Sending.
When E-mail Sending is selected for "Active"
4. Select the desired E-mail contents to transmit from the registered subject titles and the text messages
after the E-mail Sending is activated.
After the E-mail contents are selected, choose the E-mail recipients.
TRAP Transmission
5. To have a trap transmission sent after an RSH Command, select "Active" for TRAP transmission to
transmit the TRAP.
If the TRAP Transmission is not utilized, select "Inactive".
The "TRAP Command" for this product to receive when the TRAP condition occurs
OID: 1.3.6.1.4.1.20440.4.1.6.5
Name: trapPatliteRshExecuted
Designated E-mail Sender Address Setup
6. If address restrictions are made for sending an RSH Command to a designated recipient, select "Active"
for the designated sender address.
If no restrictions have been made, select "Inactive".
When "Inactive" is selected for designated sender addressing
7. Enter a common login name while the designated sender IP address is invalid.
Click the "Set" button on the lower right side of the screen for the settings to be saved.
When "Active" is selected for designated sender addressing
8. Enter the IP address into the designated sender IP address column to allow command execution. A
maximum of 16 accounts can be registered.
To allow activation for command execution, enter a login name.
9. Click the "Set" icon button to initiate the setup.
