2.1 Network Signal Tower Flowchart
The Signal Tower offers two methods for configuring the network, "Manual Network Setup", and "Automatic Network
Setup", which uses the DHCP server function.
2.1.1 Manually Setting Up Network
Signal Tower Installation
Please install this product on a level surface. If necessary, use the
accessories (rubber foot, adhesive seal, support base) if needed
when installing.
Connect the AC Adaptor to this product Using the cable clamp will
prevent the power cord from being unintentionally pulled out. (Refer
to 2.3 "Power Supply Input")
Connect the LAN cable to this product.
Set up the network environment configuration. Refer to on how to
setup the network.
Set up the detailed settings after the network environment has
been configured
This product is now ready to be used.
Power Supply Input
LAN Connection
Operation Settings
Start-up
2 Installation Procedure and Flowchart
Network Setup
Please
After completing the desired setup configuration, reboot this product
by pressing the "reset" button, or removing the power for a few
seconds and reapplying it for the changes to take effect.
