CONFIGURATION

99

Pressing Set to Minimum
sets the Holdoff time to the
minimum, 40ns.

Holdoff

40.0ns

Note: The holdoff function is automatically
disabled when the waveform update mode is
in Roll mode.

Configuring the edge trigger

Procedure

1. Press the Trigger menu key.

MENU

2. Press Type repeatedly to

select edge trigger.

Type

Edge

3. Press Source repeatedly to

select the trigger source.

Source

CH1

Range

Channel 1, 2, Line, Ext

4. Press Mode repeatedly to

select the Auto or Normal
trigger mode. To select the
single trigger mode, press
the Single key.

Mode

Auto

SINGLE

Range

Auto, Normal

5. Press Slope/coupling to enter

into the trigger slope and
coupling selection menu.

Slope /

Coupling

6. Press Slope repeatedly to

select the trigger slope,
rising or falling edge.

Slope

Range

Rising edge, falling edge
