CONFIGURATION

95

2. Press F4 repeatedly to select

voltage or current probes.

Voltage

x1

3. Use the variable knob to

edit the voltage or current
attenuation.

VARIABLE

4. The voltage/current scale in the channel

indicator changes accordingly. There is no
change in the waveform shape.

Range

0.1X~2000X (1-2-5 steps)

Note: The attenuation factor adds no influence on
the real signal; it only changes the voltage/current
scale on the display.
