SAVE/RECALL

111

Note: 2M point memory lengths are only available
for time bases slower than 10ns/div on a single
channel, and 1 M point memory lengths are only
available for time bases slower than 25ns/div on
two channels.

Waveform file
contents: other
data

A waveform file also includes the following
information.

Memory Length

Source

Vertical Units

Vertical Position

Horizontal Scale

Horizontal Mode

Firmware

Mode

Trigger Level

Probe

Vertical Scale

Horizontal Units

Horizontal Position

Sampling Period

Time

Waveform Data
