QUICK REFERENCE

45

Default Settings

Here are the factory installed panel settings which
appear when pressing the Save/Recall key→
Default Setup.

Default

Setup

Save/Recall

Acquisition

Mode: Normal

Channel

Scale: 2V/Div

Invert: Off

Coupling: DC

Probe attenuation
voltage: x1

BW limit: Off

Channel 1 & 2: On

Cursor

Source: CH1

Cursor: Off

Display

Type: Vectors

Accumulate: Off

Grid: Full

Horizontal

Scale: 2.5us/Div

Mode: Main Timebase

H Pos Adj: Fine

Hor Pos: 0

Math

Type: + (Add)

Position: 0.00 Div

Unit/Div: 2V

Measure

Item: Vpp, Vavg, Frequency, Duty Cycle, Rise
Time

Trigger

Type: Edge

Source: Channel1

Mode: Auto

Slope:

Coupling: DC

Rejection: Off

Noise Rejection: Off

Utility

Hardcopy: SaveImage,
InkSaver On

ProbeComp: Square
wave, 1k, 50% duty cycle

Go-NoGo

Go-NoGo: Off

Source: CH1

When:

Violating: Stop

(Continued)
