GDS-1000A-U Series Specifications
The specifications apply when the oscilloscope is powered on for at
least 30 minutes under +20°C~+30°C.
Model-specific specifications
GDS-1072A-U Bandwidth (–3dB) DC coupling: DC ~ 70MHz
AC coupling: 10Hz ~ 70MHz
Bandwidth Limit 20MHz (−3dB)
Trigger Sensitivity 0.5div or 5mV (DC ~ 25MHz)
1.5div or 15mV (25MHz~70MHz)
External Trigger
Sensitivity ~ 50mV (DC~25MHz)
~ 100mV (25MHz~70MHz)
Rise Time < 5ns approx.
GDS-1102A-U Bandwidth (–3dB) DC coupling: DC ~ 100MHz
AC coupling: 10Hz ~ 100MHz
Bandwidth Limit 20MHz (−3dB)
Trigger Sensitivity 0.5div or 5mV (DC ~ 25MHz)
1.5div or 15mV (25MHz~100MHz)
External Trigger
Sensitivity ~ 50mV (DC~25MHz)
~ 100mV (25MHz~100MHz)
Rise Time < 3.5ns approx.
GDS-1152A-U Bandwidth (–3dB) DC coupling: DC ~ 150MHz
AC coupling: 10Hz ~ 150MHz
Bandwidth Limit 20MHz (−3dB)
Trigger Sensitivity 0.5div or 5mV (DC ~ 25MHz)
1.5div or 15mV (25MHz~150MHz)
External Trigger
Sensitivity ~ 50mV (DC~25MHz)
~ 100mV (25MHz~100MHz)
Rise Time < 2.3ns approx.
